Gema OptiStar CG08-C User Manual

V 02/18
OptiStar CG08(-C) Product description • 9
Pneumatic data
OptiStar CG08(-C)
Compressed air connection Quick coupling
Input pressure (must be set in the system
parameter P2)
5.5 bar
6.0 bar
6.5 bar
Max. input pressure 10 bar / 145 psi
Min. input pressure (while unit in operation) 5.5 bar / 80 psi
Max. water vapor content of the compressed
air
1.3 g/m³
Max. oil vapor content of the compressed air 0.1 mg/m³
Dimensions
OptiStar CG08(-C)
Width 173 mm
Depth 250 mm
Height 177 mm
Weight approx. 3.7 kg
Powder output (guide values)
General conditions for the OptiFlow Injector
Powder type Epoxy/polyester
Powder hose length (m)
12
Powder hose Ø (mm)
11
Power hose type POE with guide strips
Input pressure (bar)
5.5
Correction value C0 Powder output zeroing adjustment
Guide values for OptiStar CG08 with OptiFlow Injector IG06
All values in these tables are guide values. Differing environmental
conditions, wear and different powder types can affect the table values.
Total air
3 Nm³/h 4 Nm³/h 5 Nm³/h
Powder output (g/min)
Powder output (%)
20
60 70 80
40
115 140 160
60
175 210 220
80
220 260 270
100
250 300 310
