V 02/18
10 • Product description OptiStar CG08(-C)
Air flow rates
The total air consists of conveying air and supplementary air, in relation
to the selected powder quantity (in %). As a result the total air volume is
maintained constant.
OptiStar CG08(-C)
Conveying air flow rate 0-5.4 Nm³/h
Supplementary air flow rate 0-4.5 Nm³/h
Electrode rinsing air flow rate 0-3.0 Nm³/h
NOTE:
The total air consumption for the device is determined based on the
3 configured air values.
These values apply for an internal control pressure of 5.5 bar!
NOTE:
The max. total air consumption during the coating operation is
< 5.5 Nm³/h:
► Total air = 5 Nm³/h (Conveying air + Supplementary air)
► Electrode rinsing air = 0.1 Nm³/h (flat jet nozzle)
