OptiStar CG08(-C) Initial start-up • 35
2. To enter the system parameter mode, press the key T12
longer than 5 seconds.
3. Press
key
The display switches to the correction factors level: The
correction factor number is shown in the display A1 with a C
placed in front
4. Check the correction value for minimum powder output C0
on the A2 display, and set it to 1.8 (Nm³/h) with the keys
T3/T4, if necessary.
5. Check the correction value for maximum powder output C1
on the A2 display, and set it to 100 (%), if necessary.
For the next steps a measuring bag is necessary, for weighing the
powder output. Do not forget to note the dead weight of the measuring
bag.
6. Put the measuring bag over the gun nozzle and fasten it.
Switch on the gun for 60 seconds
7. After this time has elapsed, switch off the gun, remove the
measuring bag and weigh it. The powder output should be
between 10-15 gr
8. If no powder is expelled from the gun, return to the system
parameter mode and increase the minimum powder output
value C0 (range 0.5-3.0 Nm³/h)
9. If too much powder is expelled from the gun, return to the
system parameter mode and decrease the minimum powder
output value C0 (range 0.5-3.0 Nm³/h)
10. Repeat steps 6 and 7, until the powder output amounts to 10-
15 g. Annotate the adjusted minimum powder output value
C0 in the table
Exit the system parameter mode by pressing the key T12.
Procedure (powder hose correction)
1. Set the powder output value to 80 (%) on the A1 display
2. Put the measuring bag over the gun nozzle and fasten it.
Switch on the gun for 60 seconds
3. Switch off the gun after 60 seconds, remove the measuring
bag and weigh it
4. Annotate the powder output in g/min in the table
Calculate the powder output correction according to following formula:
C1 (%) =
smallest powder output
x 100
measured powder output
5. Annotate the calculated values (C1) for each individual gun
in the table and enter the values to the control unit (therefore,
repeat the steps 2 and 3)
