Gemu 1436 cPos - 4 SetCalibration

29 / 66
1436 cPos
Configuration
level
Display Function Value range Factory setting
4 SetCalibration
X-Direction*
Determines the direction of
the actual value signal (rising/
falling)
rise / fall rise
W-Direction
Determines the direction of
the set value signal (rising/
falling)
rise / fall rise
W-Function The control curve is defined Lin./1:25/1:50/free lin.
Set W-free
10 control curve points can
be programmed as desired
W 0 % 0...100 %
W 10 % 0...100 %
W 20 % 0...100 %
W 30 % 0...100 %
W 40 % 0...100 %
W 50 % 0...100 %
W 60 % 0...100 %
W 70 % 0...100 %
W 80 % 0...100 %
W 90 % 0...100 %
W 100 % 0...100 %
0.0 %
10.0 %
20.0 %
30.0 %
40.0 %
50.0 %
60.0 %
70.0 %
80.0 %
90.0 %
100.0 %
Y-Direction*
Determines the direction of
the process controller output
(rising/falling)
rise / fall rise
PotiDir
Defines the direction of the
actual value potentiometer of
the valve
rise / fall rise
OutMinPos
Valve position at actual value
output signal 0/4mA
0...100 % 0.0 %
OutMaxPos
Valve position at actual value
output signal 20mA
0...100 % 100.0 %
I Min W
Switch-off limit for cable
break recognition of the set
value
0.0...22.0 mA 3.5 mA
I Max W
Switch-off limit for excess
current recognition of the set
value
0.0...22.0 mA 20.5 mA
I Min X
Switch-off limit for cable
break recognition of the
actual value
0.0...22.0 mA 3.5 mA
I Max X
Switch-off limit for excess
current recognition of the
actual value
0.0...22.0 mA 20.5 mA
Scaling
Submenu for scaling the actual value and set value display
Scaling Switches the scaled display on ON / OFF OFF
Decimalpoint
Determines the number of
digits displayed after the
decimal point
0...2 1
4 mA
Defines the display which
corresponds to a 0/4mA
signal
0 %
20 mA
Defines the display which
corresponds to a 20mA signal
100 %
Configuration
level
Display Function Value range Factory setting
5 Communication
Fieldbus
Submenu for setting the fieldbus connection
Fieldbus**
Submenu for setting the
fieldbus connection
OFF OFF
Webserver
Submenu for setting the server connection
RS 232
Defines the type of RS 232
connection
Auto
Serial
Auto
Bdrate RS
Defines the baudrate of the
RS 232 connection
38400
57600
115200
115200
*Only for activated process controllers
** Only relevant for Probus DP, DeviceNet or Pronet versions
