28 / 66
1436 cPos
Configuration
level
Display Function Value range Factory setting
3 SetFunction
Digital Output
Submenu for setting the digital outputs
K1 Switch Defines the type of output NC / NO NO
K1 Fn
Determines the function of
output K1
NO
P min
P max
P min/max
W min
W max
W min/max
X min
X max
X min/max
SSE min
SSE max
SSE min/max
Active
Error
Warning
no
AlarmMaxK1
Switch point that switches
after K1 is exceeded
0.2...99.8 % 10.0 %
AlarmMinK1
Switch point that switches
after K1 is undershot
0.2...99.8 % 90.0 %
SSE1Time
Delay time between error
recognition and error
message to K1
0.1…100.0 s 5.0 s
K2 Switch Defines the type of output NC / NO NO
K2 Fn
Determines the function of
output K2
no
P min
P max
P min/max
W min
W max
W min/max
X min
X max
X min/max
SSE min
SSE max
SSE min/max
Active
Error
Warning
no
AlarmMaxK2
Switch point that switches
after K2 is exceeded
0.2...99.8 % 10.0 %
AlarmMinK2
Switch point that switches
after K2 is undershot
0.2...99.8 % 90.0 %
SSE2Time
Delay time between error
recognition and error
message to K2
0.1…100.0 s 5.0 s
ErrorTime
Delay time between error
recognition and error
message
0.5...100 s 0.2 s
ErrorAction
Function of the process valve
if there is an error message
Close/Open/Hold/Safe Close
Warn. Time
Delay time between warning
recognition and warning
message
0.0 ... 100,0 s 0.0 s
CpyParaSet
Copies parameters to various
working memories (P1/P2/
P3/P4)
AnalogOut
Sets the function of analog
output
Poti / Ix Poti
