Gemu 1436 cPos - 2 SetBasics; Submenu for carrying out the initialisation

27 / 66
1436 cPos
Configuration
level
Display Function Value range Factory setting
2 SetBasics
W-Input Type of set value signal 4-20 mA / 0-20 mA 4-20 mA
X-Input* Type of actual value signal 4-20 mA p / 0-20 mA 4-20 mA p
Default Reset to factory settings Yes / No Yes
Init Valve
Submenu for carrying out the initialisation
GoClose Scanning the closed position
GoOpen Scanning the open position
FindFunct
The valve control function is
determined
AdjTime Scanning the operating times
FindCoefficent
Optimising the control
features
Init Pilot
Setting the minimum operat-
ing times for internal pilot
valves
CalPointQty
Quantity of calibration points
when initialising
1...19 9
D.Refresh Time for display refresh 0.1...1.0 s 0.1 s
DLight Setting the display lighting OnKey / On OnKey
AutoReturn
Time for an automatic return
to the working level - Setup
1...60min 5min
HelpLanguage Text language D / GB / N D
HelpText Display the help text ON / OFF ON
Configuration
level
Display Function Value range Factory setting
3 SetFunction
ProcCtrlMode*
Switch process controller on
or off
ON / OFF OFF
ProcCtrl*
Submenu for setting process controller parameters
Proc-P
KP amplification of the
process controller
0.0...100.0 0.5
Proc-I
KI reset time for the process
controller
0.0...999.9s 2.0s
Proc-D
KD component of the process
controller
0.0...100.0 0.0
Proc-T Process controller Tv time 1...10000 ms 1000 ms
IxType
Defines the type of actual
value filter
OFF / RC / avr OFF
IxTime
Filter time for actual value
input
0.10...20.00 s 0.10 s
PosCtrl
Submenu for setting positioner parameters
Pos P
P amplification of the
positioner
0.0...100.0** 1.0
Pos D
D amplification of the
positioner
0.0...100.0 0.0
Pos T
Decay time of the D
component of the positioner
1...5000 ms 100 ms
MinPos
Closing limit = lower position
of control range
0...100 % 0.0 %
MaxPos
Stroke limitation = upper
position of control range
0...100 % 100 %
CloseTight Lower close tight function 0...20 % 0 %
OpenTight Upper close tight function 80...100 % 100 %
DeadBand Permissible system deviation 0,1...25 %
1,0 %, K-no. 2442:
2,0 %, K-no. 2443: 5,0 %
Digital Input
Submenu for setting the digital inputs
In W
Determines the function of
the digital input "In W"
OFF / ON
Safe / ON
ParmSetB0
ParmSetB1
Poti / Ix
OFF
In X
Determines the function of
the digital input "In X"
OFF / ON
Safe / ON
ParmSetB0
ParmSetB1
Poti / Ix
OFF
In 1
Determines the function of
the digital input "In 1"
OFF / ON
Safe / ON
ParmSetB0
ParmSetB1
Poti / Ix
OFF
In 2
Determines the function of
the digital input "In 2"
OFF / ON
Safe / ON
ParmSetB0
ParmSetB1
Poti / Ix
OFF
*Only for activated process controllers
** Parameter value is automatically calculated and set by the positioner during initialisation
