Generac Power Systems VT-evo 4x290W LED User Manual

VT-evo 8mt 4x290W LED
68
TL184-01-00-04
24-07-2017
KUBOTA ENGINE
Items
Code
Denomination
1
6803
230÷240 V 16 A 2p+T EEC single phase socket
2
6188-01
Emergency stop button
3
6189-01
Contact for emergency stop button
4
16275-58-X
Aluminium front plate
5
16275-20
Box instruments
6
7806-150
Omega
7
11327
Stop terminal board
8
16320
2,5 mm² yellow/green 2 conductor terminal board (wago 2002-1207)
9
16319
2,5 mm² grey 2 conductor terminal board (wago 2002-1201)
10
16318
2,5 mm² 2 way white terminal board connection (wago 2002-402)
11
6805
230÷240 V 50 Hz hour meter
12
7996
12 V red lamp
13
10046
32x5 fuse holder
14
12175
5 A 250 V 32x5 fuse
15
13686
10 A 250 V 32x5 fuse
16
16275-57-X
Aluminium front plate
17
6150-K
Starting key (Kubota engine part)
18
11144
Monitor fuel level
19
6150-LT
Lamp timer (Kubota engine part)
20
15643
4 A 1 P (PI 6kA) circuit breaker
21
11675-07-Z
Circuit breaker support
22
12657
6p Wimex protection
23
15717
16 A RCBO combined RCD/MCB device
24
7806-150
Omega
25
15481-01
Relay support
26
6921
12 V 40 A relay
27
13271-01
10/18P (PG16) side exit terminal box
28
13271-03
10P female terminal board
29
13271-02
10P male terminal board
30
13271-04
10 poles with hook terminal box
31
13271-01
10/18P (PG16) side exit terminal box
32
6840
M8x50 Main earth terminal
