Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Specifications
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 1
Section 2 Speci fic ations
Machine Specifications
Tires and wheels
Tire size, 4 WD
(Rough Terrain)
IN315/55D20
12 ply
20 in x 11 in wheel
50.8 cm x 27.9 cm wheel
Tire weight,
new foam
-filled
(minimum)
(Rough terrain)
290 lbs
132 kg
Tire size, 4WD
(High flotation)
Tire pressure
33/16LL 500
10 ply
19.5 in x 14 in wheel
49.5 cm x 35.6 cm wheel
38 psi / 2.62 bar
Wheel lugs 9 @ 5/8 -
18
Lug nut torque, dry 230 ft-
lbs
325 Nm
Lug nut torque,
lubricated
170 ft-
lbs
244
Nm
Track Components, TRAX option
Track material
Rubber
Weight, assembly (each)
480 lbs
218 kg
Fluid capacities
LPG tank
33.5 pounds
15.2 kg
Fuel tank
20 gallons
75.7 liters
Fuel tank
(option)
30 gallons
113.6 liters
Hydraulic tank
45 gallons
170 liters
Hydraulic system
(including tank)
55 gallons
208 liters
Drive hubs
20 fl oz
592 cc
Turntable rotate drive hub
8 fl oz
237 cc
Drive hub oil type:
SAE 90 multipurpose hypoid gear oil API service
classification GL5
For operational specifications, refer to the
Operator's Manual.

Genie S-45 TRAX Specifications

General

Brand	Genie
Model	S-45 TRAX
Category	Boom Lifts
Language	English
