Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Specifications
6 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Function manifold
Function relief valve
pressure
3200 psi / 220.6 bar
Boom extend
relief valve pressure
1950 psi
134 bar
Steer regulator
all models
2 gpm / 7.6 lpm
Oscillate relief valve
pressure (@2500 rpm)
650 psi
49 bar
Traction Manifold
Hot oil relief pressure
280 psi
19.3 bar
Two
-speed drive motors, 2WD and 4WD models
Displacement per revolution
low speed
0.99 cu in / 16.3 cc
Displacement per revolution
high speed
1.83
cu in / 30 cc
Hydraulic Filters
Medium pressure filter
Beta 3 ˆ 200
Medium pressure filter bypass
pressure
51 psi
3.5 bar
Hydraulic tank return filter
10 micron with
25 psi / 1.7 bar
bypass
Manifold Component
Specifications
Plug torque
SAE No. 4
13 ft-
lbs / 18 Nm
SAE No. 6
18 ft-
lbs / 24 Nm
SAE No. 8
50 ft-
lbs / 68 Nm
SAE No.10
55 ft-
lbs / 75 Nm
SAE No. 12
56 ft-
lbs / 75.9 Nm
