Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Platform Components
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 35
How to Bleed the Slave Cylinder
1 Simultaneously activate the primary boom up
function and the platform level up function until
the boom is fully raised.
2 Simultaneously activate the primary boom
down function and the platform level down
function until the boom is fully lowered.
2-2
Platform Rotator
The platform rotator is a hydraulically activated
helical gear assembly used to rotate the platform
160 degrees.
How to Remove the Platform
Rotator
Component damage hazard.
Mark the platform mounting
weldment and the rotator flange
before removing the platform
mounting weldment. The
platform mounting weldment
must be r
eplaced in the exact
same position on the rotator
flange as it was before removal.
If a new rotator is installed or the
rotator is disassembled, proper
alignment can be achieved by
rotating the rotator all the way to
the left and then installing the
platfo
rm mounting weldment all
the way in the left position.
Note: When removing a hose assembly or fitting,
the O-ring (if equipped) on the fitting and/or hose
end must be replaced. All connections must be
torqued to specification during installation. Refer to
Specifications, Hydraulic Hose and Fitting Torque
Specifications.
1 Remove the platform and platform support.
Note: If the load sense components are
disassembled and/or removed from the platform
support, the platform load sense system will need
to be calibrated. Refer to Repair Procedure,
Platform Load Sense System.
