Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Specifications
8 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Deutz D2011 L03i Engine
Displacement
142 cu in
2.33 liters
Number of cylinders
3
Bore and stroke
3.7 x 4.4 inches
94 x 112 mm
Horsepower
48 @ 2800 rpm
36 kW @ 2800 rpm
Firing order
1 - 2 -
3
Low idle
1500 rpm
313 Hz
High idle
2500 rpm
521.7 Hz
Compression ratio
19:01
Compression pressure
362 to 435 psi
25 to 30 bar
Governor
centrifugal mechanical
Valve clearance, cold
Intake
0.012 in
0.3 mm
Exhaust
0.020 in
0.5 mm
Lubrication system
Oil pressure
20 to 44 psi
1.4 to 3 bar
Oil capacity
(including filter)
9.5 quarts
9 liters
Oil viscosity requirements
-
22° F to 86° F/ -30° C to 30° C 5W-
30 (synthetic)
-
4° F to 90° F / -20° C to 32° C 10W-
40
Above 23° F /
-5° C 20W-
50
Units ship with 15W
-40.
Extreme operating temperatures may require the use of
alternative engine oils. For oil requirements, refer to the
Engine Operator Handbook on your machine.
Oil temperature
switch
Temperature switch point
300°F
149°C
Oil pressure switch
Oil pressure switch point
22 psi
1.5 bar
Fuel injection system
Injection pump make
Bosch
Injection pump pressure,
maximum
15000 psi
1034 bar
Injector opening pressure
3046 psi
210
bar
Fuel requirement
For fuel requirements, refer to the engine Operator's
Manual on your machine.
Starter motor
Current draw, no load
90A
Brush length, new
0.72 in
18.5 mm
Brush length, minimum
0.27 in
7 mm
Battery
Type
12V DC, Group 34/78
Quantity
1
Cold cranking ampere
900A
Reserve capacity @ 25A rate
200 minutes
Alternator output
60A @ 14V DC
Fan belt deflection
3/8 to 1/2 inch
9 to 12 mm
