Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Specifications
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 5
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade
46
Viscosity index
192
Kinematic Viscosity
cSt @
149°F / 65°C
cSt @ 104°F / 40°C
cSt @ 0°F /
-18°C
22
46
1300
Flash point
None
Pour point
-81°F / -
63°C
Maximum continuous operating
temperature
189°F / 87°C
Hydraulic Component
Specifications
Drive Pump
Type:
bi-directional variable displacement piston pump
Flow rate @ 2500 rpm
0 -
28 gpm
0 -
122.6 L/min
Drive pressure, maximum
3625 psi
250 bar
Charge Pump
Type
gerotor
Displacement per revolution
0.85 cu in
13.9 cc
Flow rate @ 2500 rpm
9 gpm
34 L/min
Charge pressure @ 2500 rpm
310 psi
21.4 bar
Function pump
Type
gear, pressure
balanced
Displacement
1.04 cu in
17 cc
Flow rate @ 2500 rpm
10.69 gpm
40.5 L/min
Auxiliary Pump
Type: fixed displacement gear pump
Displacement per revolution
1.75 gpm
6.62 L/min
Auxiliary pump relief pressure
3200 psi
220.6 bar

Genie S-45 TRAX Specifications

General

Brand	Genie
Model	S-45 TRAX
Category	Boom Lifts
Language	English
