Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Specifications
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 9
Deutz D 2.9 L4 Engine
Displacement
177 cu in
2.9 liters
Number of cylinders
4
Bore and stroke
3.6 x 4.3 inches
92 x 110 mm
Horsepower
48.8 @ 2600 rpm
37 kW @ 2600 rpm
Firing order
1 - 3 - 4 -
2
Low idle
1500 rpm
313 Hz
High idle
2500 rpm
521.7 Hz
Compression ratio
18.4:1
Compression pressure
362 to 435
psi
25 to 30 bar
Governor
electronic
Lubrication system
Oil pressure (@ 2000 rpm)
40 to 60 psi
1.4 to 3 bar
Oil capacity
(including filter)
9.4 quarts
9 liters
Oil viscosity requirements
-
22° F to 86° F/ -30° C to 30° C 5W-
30 (synthetic)
-
4° F to 90° F / -20° C to 32° C 10W-
40
Above 23° F /
-5° C 20W-
50
Units ship with 15W
-40.
Extreme operating temperatures may require the use of
alternative engine oils. For oil requirements, refer to the
Engine Operator Handbook on your machine.
Oil temperature
switch
Temperature switch point
257°F
125°C
Oil pressure switch
Oil pressure switch point
20 psi
1.4 bar
Engine coolant
Capacity
10 quarts
9.4 liters
Fuel injection system
Injection pump make
Bosch
Injection pump pressure,
maximum
15000
psi
1034 bar
Injector opening pressure
3046 psi
210 bar
Fuel requirement
For fuel requirements, refer to the engine Operator's
Manual on your machine.
Starter motor
Cranking speed
150-
250 RPM
Current draw, normal load
250A to 400A
Output
3.2kW
Battery
Type
12V DC
Quantity
1
Cold cranking ampere
1000A
Reserve capacity @ 25A rate
200 minutes
Alternator output
95A @ 14V DC
Fan belt deflection
3/8 to 1/2 inch
9 to 12 mm
