Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Specifications
12 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Machine Torque Specifications
Platform rotator
1-8 center bolt, GR 5
Dry
615 ft-
lbs
834 Nm
3/8
-16 bolts, GR 8
Dry
*(use blue thread locking compound)
35 ft-
lbs*
47.5 Nm*
Turntable rotate assembly
Rotate bearing mounting bolts, lubricated
160 ft-
lbs
217 Nm
Drive motor/brake mounting bolts, dry
*(use blue thread locking compound)
49 ft-
lbs*
66.4 Nm*
Drive
motor/brake mounting bolts,
lubricated
37 ft-
lbs
50 Nm
Drive motor and hubs
Drive hub mounting bolts, dry
210 ft-
lbs
284 Nm
Drive hub mounting bolts, lubricated
160 ft-
lbs
217 Nm
TraX™ Torque Specifications
Hub adapter to
drive hub fasteners
Lug nut torque, dry
230 ft-
lbs
312 Nm
Lug nut torque, lubricated
170 ft-
lbs
230 Nm
Idler and bogey wheel fasteners
3/4
-10 bolts, GR 8, dry 375 ft-
lbs
508 Nm
3/4
-10 bolts, GR 8, lubricated 281 ft-
lbs
381 Nm
