Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Specifications
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 7
Ford MSG-425 EFI Engine
Displacement
153 cu in
2.5 liters
Number of cylinders
4
Bore & stroke
3.5 x 3.9 inches
89 x 100 mm
Horsepower
60 @ 2500 rpm
45 kW @ 2500 rpm
Firing order
1 - 3 - 4 -
2
Low engine idle (computer
controlled)
1000 rpm
33.3 Hz
Low function idle (computer
controlled)
1600 rpm
53.3 Hz
High function idle (computer
controlled)
2500 rpm
83.3 Hz
Compression ratio
9.7:1
Compression pressure (approx.)
Pressure (psi or bar) of lowest cylinder must be at least
75% of highest cylinder
Lubrication system
Oil pressure
(operating
temperature @ 2000 rpm)
29 to 39 psi
2.75 to 4.1 bar
Oil capacity (including filter)
6.7 quarts
6.4 liters
Oil pressure switch
Oil pressure switch point
7.5 psi
0.51 bar
Oil viscosity requirements
Extreme operating temperatures may
require the use of
alternative engine oils. For oil requirements, refer to the
Engine Operator Handbook on your machine.
Electronic fuel pump
Fuel pressure, static
60 psi
4.1 bar
Fuel flow rate
0.58 gpm
2.2 L/min
Fuel requirement
For fuel
requirements, refer to the engine Operator's
Manual on your machine.
Ignition system
Spark plug type
Motorcraft AYFS-32Y-
R
Spark plug gap
0.049 to 0.053 inches
1.25 to 1.35 mm
Engine coolant
Capacity
11.5 quarts
10.9 liters
Coolant temperature
switch
Temperature switch point
230°F
110°C
Starter motor
Normal engine cranking speed
200 to 250 rpm
Current draw, normal load
140-
200A
Current draw, maximum load
800A
Alternator
Output
95A, 13.8V DC
Battery
Type
12V DC, Group 34/78
Quantity
1
Cold cranking ampere @ 0°F
900A
Reserve capacity @ 25A rate
200 minutes
