Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Primary Boom Components
52 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
4-7
Boom Length Sensor
How to Calibrate the Primary
Boom Length Sensor
Note: The turntable level sensor and platform load
sensor must be calibrated prior to calibrating the
primary boom angle sensor.
Note: The turntable level sensor, platform load
sensor, and primary boom angle sensor must be
calibrated before calibrating the boom length
sensor.
Note: This procedure will establish the cross-check
angle with the boom limit switch LSB1RS. If
LSB1RS does not switch its state properly during
calibration, the calibration will be invalidated.
1 Fully retract the boom. Ensure the boom angle
is above 65°.
2 Enter Service Mode. See Repair Procedure,
How to Enter Service Mode.
3 Press the settings button above the display
and navigate to Sensor Calibrations.
4 Navigate to the Boom Length Sensor
calibration screen.
5 Select and start the calibration procedure.
6 Start the engine.
7 When the display prompts the operator to
retract the boom, press and hold the function
enable and boom retract buttons until the
display indicates the retracted calibration point
has been obtained. This may require holding
the buttons for several seconds after the boom
has fully retracted.
8 Press the OK button to continue to capture
the maximum extension point.
9 Press the function enable and boom extend
buttons until the boom reaches its maximum
extension. Continue holding the buttons for
several seconds after the boom reaches its
maximum extension until the display indicates
the calibration point has been captured.
10 The calibration is complete.
11 Exit the Service Mode.
