Service and Repair Manual July 2019
Specifications
2 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Performance Specifications
40 ft / 6.8 -
12.2 m / 6.8 -
40 ft / 40 -
12.2 m / 40 -
speeds,
40 ft / 9 -
12.2 m / 9 -
40 ft / 40 -
12.2 m / 40 -
Braking distance, maximum
High range on paved surface
3 -
0.9 -
Boom function speeds, maximum
-45 models 48 - 53 seconds
-45 models 28 - 33 seconds
nge of motion)
3 -
50 - 60 seconds
50 - 60 seconds
extend 30 - 60 seconds
15 - 35 seconds
70 -
120 -
For operational specifications, refer to the
Operator's Manual.
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a wide
temperature range, and the viscosity index
should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Cleanliness level,
minimum
Hydraulic Fluid
Optional Hydraulic Fluids
Shell Tellus S2 V 32
Shell Tellus S2 V 46
Shell Tellus S4 VX 32 Shell
Shell Donax TG (Dexron III)
Chevron 5606A
Petro Canada Environ MV
UCON Hydrolube HP-
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
ptional fluids may not have
the same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond it's
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
