Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Repair Procedures
16 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Section 3 Repai r Pr oc edur es
Observe and Obey:
 Repair procedures shall be completed by a
person trained and qualified on the repair of
this machine.
 Immediately tag and remove from service a
damaged or malfunctioning machine.
 Repair any machine damage or malfunction
before operating the machine.
Before Repairs Start:
 Read, understand and obey the safety rules
and operating instructions in the appropriate
operator's manual on your machine.
 Be sure that all necessary tools and parts are
available and ready for use.
 Use only Genie approved replacement parts.
 Read each procedure completely and adhere
to the instructions. Attempting shortcuts may
produce hazardous conditions.
Machine Configuration:
 Unless otherwise specified, perform each
repair procedure with the machine in the
following configuration:
• Machine parked on a firm, level surface
• Key switch in the off position with the key
removed
• The red Emergency Stop button in the off
position at both the ground and platform
controls
• Wheels chocked
• All external AC power supply disconnected
from the machine
• Boom in the stowed position
• Turntable secured with the turntable rotation
lock

Genie S-45 TRAX Specifications

General

Brand	Genie
Model	S-45 TRAX
Category	Boom Lifts
Language	English
