July 2019 Service and Repair Manual
Repair Procedures
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 17
About This Section
Most of the procedures in this section should only
be performed by trained service professional in a
suitably equipped workshop. Select the appropriate
repair procedure after troubleshooting the problem.
Perform disassembly procedures to the point
where repairs can be completed. Then to
re-assemble, perform the disassembly steps in
reverse order.
Symbols Legend
—
used to alert
personnel to po
tential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially haz
ardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Indicates that a specific result is expected
after performing a series of steps.
Indicates that an incorrect result has occurred
after performing a series of steps.
