Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Control System
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 25
1-7
Display Module Menus
Screen or Menu Item Default
Display Settings Backlight 0 - 100%
Contrast 0 - 100%
Display Inversion On / Off
Screen or Menu Item Selections Default
Model Configuration
(These are locked
unless factory defaults
are restored)
Model S40 / S45 / S-60 / S-65 / S80 / S-85 <select model>
Engine Deutz 2.9L / Deutz Turbo 2.9L /
Deutz D2011 L03i / Deutz TD2011
L04i / Perkins 404D-22 / Perkins
404D-22T / Perkins 404F-E22T /
Ford MSG425 / GM 3.0L
<select engine>
Tires Rough Terrain / High Float (region
specific), TRAX (region specific)
<select tires>
Region ANSI/CSA / AUS / CE <select region>
Screen or Menu Item Selections Default
Options Footswitch Timeout 10 sec / 2 min / 30 min 2 min
Note: Some options
may not be visible with
earlier software
revisions.
Drive Priority ON / OFF OFF (This cannot
be turned
off if CE region is selected)
Drive Cutout ON / OFF OFF
Platform Level ON / PRIORITY / CUTOUT ON
Generator NO GENERATOR / GENERATOR
INSTALLED
NO GENERATOR
Contact Alarm ON / OFF ON
Platform Recirculation ON / OFF OFF
Units US CUSTOMARY / METRIC US Customary
Aircraft Proximity ON / OFF OFF
Fuel Level Sensor NOT INSTALLED / INSTALLED NOT INSTALLED
Glowplug Preglow Time 1 sec - 100 sec 12 sec
Lift Connect NOT INSTALLED / INSTALLED INSTALLED
Alarm Setting OFF / TRAVEL / MOTION OFF
4m Platform NOT INSTALLED / INSTALLED NOT INSTALLED
