Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Control System
26 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Screen or Menu Item Default
Sensor Calibration Chassis Tilt select OK to Calibrate
Load Sense select OK to Calibrate
Boom Angle select OK to Calibrate
Boom Length select OK to Calibrate
Factory Defaults select OK to Restore Factory Defaults
Screen or Menu Item Default
Auto Threshold
Calibration
Boom Up / Down Threshold select OK to Calibrate
Screen or Menu Item Default
Drive Speeds
XC and HF
Forward Threshold 128% max, 1% min, 100% = 723 mA (default)
Reverse Threshold 131% max, 1% min, 100% = 690 mA (default)
Forward Max 150% max, 74% min, 100% = 1556 mA (default)
Reverse Max 150% max, 74% min, 100% = 1129 mA (default)
Forward Out of Stow Max 150% max, 82% min, 100% = 1140 mA (default)
Reverse Out of Stow Max 150% max, 81% min, 100% = 1129 mA (default)
Screen or Menu Item Default
Drive Speeds
TraX
Forward Threshold 149% max, 1% min, 100% = 730 mA (default)
Reverse Threshold 152% max, 1% min, 100% = 708 mA (default)
Forward Max 150% max, 64% min, 100% = 2700 mA (default)
Reverse Max 150% max, 65% min, 100% = 2500 mA (default)
Forward Out of Stow Max 150% max, 76% min, 100% = 1455 mA (default)
Reverse Out of Stow Max 150% max, 75% min, 100% = 1451 mA (default)
