GV-AS100 Controller
47
1
1.6 Specifications
1.6.1 GV-AS100
CPU 8-bit RISC microprocessor
Number of User Cards 1,000 / 40,000 cards (standalone / networked mode)
Event Buffer 65,536 events and log data
Power 100 ~ 240V AC, 50 ~ 60Hz
1 Wiegand interface, 26 ~ 64 bit format
Wiegand Interface
12V DC Power Supply, 200mA
Communication Protocol RS-485
Input 3 inputs, dry contact, NO / NC
Digital I/O
Output 2 outputs
Operating Temperature 0 ~ 65°C / 32 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions
(W X H X D)
96 x 137 x 27 mm / 13.78 x 5.39 x 1.06 in
Weight 250 g / 8.8 Ib
Certification CE, FCC, RoHS
