Box Camera
11
1
1. If you are using the auto iris model, plug the iris control cable to the
Auto Iris Connector on the camera.
2. Use a standard network cable to connect the camera to your network.
3. Optionally connect a speaker and an external microphone.
4. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting the signal format at the
TV Out field on the Web
interface. See
TV Out setting, in the Video Settings section,
Administrator Mode Chapter, GV-IPCam H.264 User’s Manual on the
software CD.
5. Connect power using one of the following methods:
• Plug the supplied power adapter to the DC jack.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
6. Optionally connect to input / output devices or an infrared illuminator.
For details, see
Infrared Illuminator and I/O Terminal Block, Box
Camera
Chapter, GV-IPCam H.264 User’s Manual on the software
CD.
7. The status LED of the camera will be red.
8. You are ready to access the live view and adjust the image clarity. See
9. Accessing the Camera in the Quick Start Guide.
