Communication settings
Baud Data Stop Parity
57600 8 1 None
System settings
Label Value
Scotchcal 220 material Selected
HPGL units 0.01 mm/unit
Pounce Type Off
Pulldown 24" (61 cm)
Run mode Single
Text Display English
Use rule sets On
Communications
The communication settings on your computer and plotter must match.
Plotter settings are preset at the factory to communicate with OMEGA
and GRAPHIX ADVANTAGE. If you are not using either of these, you
can change either the computer settings or the plotter settings.
The table shows the RS-232 interface parameters, default factory setting,
and possible plotter settings for each parameter. Refer to the manuals
that come with your computer and software for information about
settings required at the computer.
Parameter Default Possible Settings
Baud Rate 57600 4800, 9600, 19.2K, 38.4K,
57.6K, 115.2K
Data Length 8 bit 8, 7, 6, 5
Parity None None, Even, Odd
Stop bit 1 bit 1, 2, 1.5
