Gerber ODYSSEY XP - Cut Strip Replacement

69
Cut strip replacement
Replacement strips can be purchased from your distributor. Follow the
procedures below to replace the cut strip.
To replace the cut strip
1
Remove the worn cut strip by lifting it up at one end and pulling it
straight up together with the underlying adhesive.
2
Clean the exposed surface with alcohol to remove any adhesive where
the strip was attached. Without a clean, flat surface, the new cut strip
will not stick properly.
3
Remove the protective backing from the replacement strip and insert
the strip into the groove.
4
Press the cut strip firmly along its entire length to assure tight, even
adhesion. The strip must be flat for the entire length.
Note: After the cut strip is replaced, you must recalibrate the Y-beam.
To calibrate Y-beam
1
Insert a knife holder UPSIDE DOWN in the carriage.
2
Raise the pinch wheels by pushing the pinch wheel lever back.
3
Push back on the grip handle and slide grit wheels to the 40" location,
then slide the pinch wheels to match the grit wheels.
4
Lower the pinch wheels by pulling the pinch wheel lever toward you.
Reply
Ignore
to the message that no material is in the plotter.
5
Lift the middle pinch wheel pressure lever.
6
Press F3 (Search) to have the plotter search for the pinch wheels.
7
While holding down Enter, press F4.
8
Press F2 to proceed.
9
Press F1 (Calibrate).
10
Press F1 (Y Beam). As the plotter moves the carriage, DO NOT LEAN
ON OR MOVE THE PLOTTER ANYWHERE AT THIS TIME.
11
After calibration is complete, press F4 to save the results.
12
Press Enter to return to the Main Menu.
