The ODYSSEY XP calculates the job extremities when it receives a job.
If the job will not fit or the starting position must be adjusted, it
displays an appropriate message (when used with OMEGA or GA).
♦
Repeats (up to 9999 copies) of the last job plotted can be run from the
ODYSSEY XP.
♦
The operator can suspend a job, move the material for easy viewing,
and resume the job without affecting the material or job.
♦
You can upgrade the plotter firmware by downloading new firmware
from your PC.
In this manual
This manual contains the following sections:
Introduction presents basic information about this manual.
Getting Started tells you how to connect the ODYSSEY XP, use the
control panel and menus, load material, and install tools.
Running Jobs presents the procedures for using the ODYSSEY XP
control panel for cutting, plotting, and pouncing single and multiple
jobs.
Tool Settings shows how to use either the plotter or Gerber OMEGA or
GA software to choose tool settings.
Advanced Functions describes functions beyond routine job cutting.
Troubleshooting provides a list of error messages and possible
solutions.
Maintenance describes routine cleaning and replacement procedures.
HPGL Support presents information about using the HPGL command
set to support the ODYSSEY XP plotter.
Conventions used in this manual
The following conventions are used in this manual:
WARNING: A warning statement contains information which, if not
observed, could result in personal injury.
CAUTION: A caution statement contains information which, if not
observed, could result in damage to the equipment.
Note: A note contains important information which could affect successful
completion of a task.
