Appendix:
Specifications
Material Width 4"-52" (127.0 mm-1321 mm)
Cutting Width up to 49" (1244.6mm)
Max. Media Thickness 0.045" (1.1mm)
Driving Mechanism GerberDrive
Knife/Cut Type/Principle Swivel
Mechanical Resolution 0.0002" (0.005mm)**
Number of Pressure Rollers 3
Knives 30 /45 /60 Offset 0.02 inches
Pens HP Compatible
Max Cutting Speed (Axial) 36 ips (914mm/s)
Max Cutting Speed (Diagonal) 50 ips (1270mm/s)
Acceleration Knife Up/Down 3G
Knife Up/Down Cycles 40/second
Adjustable Knife Pressure 0.0oz – 16oz (0g-454g)
Interfaces (Standard) RS-232C
Input Buffer 250Kb
Stand Standard
Pounce Optional Tool/Pounce Mat
Unboxed Dimensions (with Stand) 70"L x 12.25"W x 49.5" H
Boxed Dimensions (with Stand) 73"L x 29"W x 24"H
Unboxed Weight 200 lbs.
Boxed Weight (With Stand) 285 lbs.
AC Power Requirements 100-230v 47/63 Hz
Software Command Language GSP/GL or HPGL/S subset
Vector Look Ahead Yes
Curve & Arc Smoothing Yes
Test Plot Possibility Yes
Test Cut Possibility Yes
Replot Function Yes
* Plotter specifications subject to change and may be modified without notice.
** Typical job accuracy is 0.1%. For maximum accuracy, job length should be 10 feet or
less with an undamaged material edge.
