53
Appendix A
Specifications
NOTE: Specifications are subject to change without any prior notice.
Parts Specifications
CPU Intel® Bay Trail-M processor
BIOS Insyde, Flash EEPROM, supporting UEFI
RAM 2GB/4GB DDR3L 1066/1333MHz SO-DIMM
Video Controller UMA - Intel® HD Graphics
Display
Panel
8.1-inch (16:10) TFT LCD, 1280 x 800 resolution,
sunlight readable, dimmer mode, blackout mode,
600 Nits
Touchscreen Capacitive multi-touch screen - 5 points
Audio Features Azalia, High Definition audio
Speaker 1.5W x 1
Microphone Integrated microphone
Hard disk drive SATA 2.0, 64/128 GB SSD (Solid-State Disk)
I/O
ports
Standard
USB 3.0, combo audio (4-pole TRRS 3.5mm type),
micro HDMI, Docking, Expansion
Optional
One of the below options on the top side:
RS232 / RJ-45 / microSD / barcode scanner
LAN (option) 10/100/1000 Mbps Ethernet
Wireless LAN + BT
Integrated 802.11ac Wi-Fi, IEEE 802.11a/b/g/n
compatible, BT 4.0 + EDR
GPS NMEA0183
WWAN 3G/4G LTE
