Software description and settings 5
Service instructions
5015108-00Edition 0403
>PRINT LAST CYCLE
SYSTEM V
>SYSTEM ^
ABOUT
SYSTEM ^
>ABOUT
The angle bracket “>” to the left of the top line shows which object will be chosen if you press
S. Bottom right there is a “v” indicating that there are more objects in the list which are
displayed if you press J.
This is what you see if you are in a list. The “arrows” to the right show that there are objects
both above and below the displayed line.
When you reach the end of the object list, only one up-arrow appears at the right edge of the
displayed. Menus and lists are “endless”; you can reach the top of the list by pressing J at
the end of the list.
Buttons for menu tree navigation
The are five buttons for navigating the panel. These fixed buttons are four arrow buttons that
control the cursor (I, K, J and H) and S.
I Used to go back one step (up one level) in menus. If the button is held down for a little
longer, you are returned to the main menu.
K Not used in menus and lists.
J Shows the next object in the list.
H Shows the previous object in the list.
S Goes to the chosen object in the list or opens a field for editing if there is an editable field.
Scroll in menus and lists
You can use I, K, J and H to scroll through menus and lists. You can scroll either line
by line or two lines at a time, depending on what is displayed. The top line of the list may look
like the example below.
Field editing
S opens the chosen field for editing. The content of the field is changed with H or J.
These arrow keys scroll in an endless list containing numbers. When a field is opened for
editing, the first character is highlighted. To move the cursor use I or K.
Entered values are saved when you press S. On saving, the system checks that the value is in
the permitted range.
