Description
6
Service instructions
5015108-00 Edition 0403
Safe and simple
The disinfector is controlled by a microprocessor. This has several advantages:
• the built-in service program makes troubleshooting and servicing far easier
• safety and reliability can be kept high by continuous monitoring of the process
• the dosing of detergent, the temperature and the disinfection time can all be altered with
great precision to suit different conditions.
The programs can be adapted precisely to suit the needs of each user. Existing programs can be
re-programmed via a PC. As standard, the washer-disinfector has two to six programs.
The door and wash chamber are well insulated, so that the washer-desinfector is energy-
efficient and silent in operation.
Operation is simple and the control buttons and few and clearly marked.
Programming may only be done by authorised personnel.
Simple service and installation
Valves and electrical equipment are easily accessible from the front for inspection and service.
Door function
The washer-disinfector can be fitted with a single door or double doors. All doors are of the
vertical sliding type.
The doors can be motorised for automatic opening and closing. The doors have efficient anti-
crush protection.
Machines with double doors have a system of interlocks to ensure that only one door can be
opened at a time. This means that the clean-side door must be closed and locked by pressing
the W button before the dirty-side door can be opened.
When V is pressed, the door is locked and a yellow lamp flashes (process running) for about
10 seconds. If V is pressed again during this “cancel time”, the dirty-side door is unlocked and
the door can be opened manually or alternatively it opens automatically.
The doors can be locked an unlocked individually from the service program (authorisation required).
Manually-operated door
When the door is closed manually and V is pressed, the door is clocked automatically, the
yellow lamp flashes and the program starts.
When the program is complete, a green lamp lights up on both sides (if there are double doors)
and the clean-side door is unlocked. When the door has been opened manually, the green lamp
goes out. With double doors, the clean-side door must be closed manually and locked by
pressing the W button before the dirty-side door can be unlocked.
A manually-closed door can be opened by pressing the U button for about five seconds. Press
U to unlock the door.
