Description
11
Service instructions
5015108-00Edition 0403
Fast-stepping a program
All safety functions are disabled for fast stepping.
Fast stepping must only be used during servicing.
Never stop fast stepping in a heating phase. If you do, the machine may
be damaged.
An ongoing program can be fast-stepped phase by phase. Fast stepping can be chosen during
an ongoing process.
1. Fast stepping is chosen in the service program; see tab 5 Software description and setting,
under DIP switches display (1.4.2.4).
2. Set DS02 STEP in STATUS to 1 and press S . Exit the service program.
3. Fast-step with U.
4. Reset DS02 STEP STATUS to 0 and press S . Exit the service program.
Reset DS02 STEP STATUS to 0 after completion of fast stepping.
