Repair and adjustment
5
Service instructions
5015108-00Edition 0403
Barcode scanner
To connect a barcode scanner, proceed as follows.
1. Connect power to the scanner.
2. Connect a communication cable between the scanner
and port X24.
3. Set type of communication. The communication
settings are done in the service program; see under
tab 5 Software description and settings.
- Go into Communication setup COM 0 (1.4.2.3.5.1);
see tab 5 Software description and settings.
- Choose Scanner and press S. Exit the service
program.
Barcode
scanner
