Description
7
Service instructions
5015108-00Edition 0403
Automatically-operated door
WhenVis pressed, the door is locked, the yellow lamp flashes and the program starts.
When the program is complete, a green lamp lights up on both sides (if there are double doors)
and the clean-side door opens automatically. When the door is fully open the green lamp goes
out on both sides. With double doors, the clean-side door must be closed and locked by
pressing the W button before the dirty-side door opens automatically.
An automatically-operated door can be closed on the dirty side without starting a process.
Press and hold U for about five seconds. The door is closed and locked automatically. Press U
to unlock the door.
Dosing system
In standard form, the machine has two different dosing systems. One is for alkaline detergent and
one is for rinse-aid or acid detergent. The dosing amount can be set individually for each program.
The machine cannot be started until detergent has been dispensed. If the detergent holder is
empty “DOS 1-4 Low level” appears on the display.
A third and a fourth dosing system for heat-sensitive goods or instrument milk, for example, can
be installed.
Dosing pumps for:
1 Alkaline detergent
2 Rinse-aid or neutralisation
3 Instrument milk or enzyme agent (option)
4 Chemical disinfection (option)
V1313
1
2
4
3
1
2
3
V1576
Chamber depth 720 mm Chamber depth 800 mm
