Godex GS220 - Light Pen Parameters; Light Pen Mode Settings

13–1
Light Pen Parameters
³415524
Enable Light Pen Mode – Select this option if
the scanner will be used in place of a light pen.
It provides light pen emulation of each bar code
scanned.
³116917
* Bars High
³116907
Spaces High
³116916
Transmit as Code 39 – All bar codes will be
decoded then transmitted as Code 39 bar codes.
³116906
* Transmit as Scanned – All bar codes will be
decoded and transmitted in that symbology.
³116915
Poll Light Pen Source – The scanner waits for
an active source voltage before transmitting data.
³116905
* Do Not Poll Light Pen Source
³116911
Enable Inverted IDLE/Extra Toggle – The
scanner beeps and toggles the light pen data line
with an extra data pulse to condition the decoder.
³116901
* Disable Inverted IDLE/Extra Toggle
³116910
Enable Pre-Transmit Toggle of RTS Line
³116900
* Disable Pre-Transmit Toggle of RTS Line
