SOUL S5110/ART 7W VIDEO DOOR ENTRY SYSTEM KIT
11
ART 7W/G2+ MONITOR
Main menu
09:27PM
17 2-1 -2019 Thu
Door panel Intercom function Recordings Settings
If the device is in standby (screen off), touch any part of the screen to activate it and bring up the main menu. The
device will return to standby mode after 20 seconds without activity.
Note: ART 7W/G2+ monitor 'V.01 + No. 6539 and V.02' or later: This enables the door panel
camera to be changed, the audio of the corresponding door panel to be activated and the door to
be opened.
Display the image from the door panels and cameras connected to the system.
Access the menu for intercom with other monitors in the system.
Display the list of images recorded in the device memory. If there are new or unseen images, the
number will be displayed in the top right of the icon and notification icon will illuminate. If the
number is greater than 9, three points will be displayed.
Change the system settings.
No function. The button can be set to be displayed or not in the main menu, see 'Screen' settings on
p. 13.
Indicates that the inserted MicroSD card must be formatted from the monitor. Press to access the
storage functions menu and format the card.
Press to activate or deactivate Wi-Fi transmission. The icon will change colour (white on, grey off) and
notification icon will illuminate depending on the status.
Press for 3 seconds to activate/deactivate Wi-Fi transmission.
Note:ART 7W/G2+ monitor 'V.01 + No. 6539 and V.02' or later:
Important: Only the master monitor can activate Wi-Fi transmission.
Press for 3 seconds to activate or 1 second to deactivate the 'Do not disturb' function (the
monitor does not sound when a call is received). The notification icon will illuminate
depending on the status.
2 ...
No function. The button can be set to be displayed or not in the main menu, see 'Screen' settings on
p. 13.
Important: New main menu with ART 7W G2+ monitor with V.04 and later.
