SOUL S5110/ART 7W VIDEO DOOR ENTRY SYSTEM KIT
5
SOUL PANEL
Description
A
B
C
F
E
D
J
I
G
J
G
H H
B
C
D
L
M M
K M
Q
O
O
P
I
N
T
K
R
S
R. Configuration switches.
T. Proximity reader configuration button.
Q. Proximity reader connector.
S. Volume control potentiometer.
A. System status icons:
C. Ambient lighting sensor.
E. Protective polycarbonate.
F. Proximity card reader.
M. Wall fixing hole (x3). Do not overtighten the
fixing screws.
L. Proximity reader.
G. Speaker grill.
N. Proximity reader gasket.
Communication established.
B. System status indicator lights.
O. Installation terminals.
Lock release activated.
P. Cable grommet.
D. Night viewing lighting.
I. Call button(s).
J. Microphone hole.
K. Front fixing screw.
H. Colour camera.
Call in progress.
System busy.
