SOUL S5110/ART 7W VIDEO DOOR ENTRY SYSTEM KIT
32
WIRING DIAGRAMS
One apartment with one access panel and one monitor
One apartment with two access panels and one monitor
BUS (M)
BUS (M)
BUS PL( )
BUS PL( )
L
L
N
N
Mains
100~240Vac
Mains
100~240Vac
BUS BUS BUS BUS
BUS BUS BUS BUS BUS BUS
Cross sections and distances
- The maximum number of monitors in daisy chain
connected is 12.
- The maximum number of monitors per apartment is 4.
FA-G2+
FA-G2+
Type of cable A B C
2 x 0 75mm² ( 18). AWG 30 m 30 m 15 m
60 m 60 m 30 m
60 m 60 m 30 m
CAT5 (*)
RAP GTWIN HF- /
A. Distance between power supply and furthest door panel.
C. Distance between a distributor and the furthest monitor connected to one
of its outputs.
B. Distance between power supply and furthest monitor (or distributor).
(*). Use two twisted pairs for each bus line
FA-G2+
C C
B
A
ART 7 /G2+W ART 7 /G2+W
SOUL/1
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7
8
APARTMENT 1
MASTER MONITOR
APARTMENT 1
MASTER MONITOR
PANEL 2
SOUL/1
PANEL 1
SOUL/1
PANEL 1
SOUL/1
ART 7 /G2+W
ART 7 /G2+W
