SOUL S5110/ART 7W VIDEO DOOR ENTRY SYSTEM KIT
3
SYSTEM OPERATION
To open door or activate auxiliary output of the door panel, press the corresponding icon. A single press
activates the lock release or auxiliary output for 3 seconds, and LED on the door panel illuminates. The activation
time is programmable, as indicated on pp. 40-41.
To establish communication, press off-the-hook icon on the screen. Door panel LED will illuminate. Connection
will last for 90 seconds or until on-the-hook icon is pressed. When communication ends, LED will turn off and
the system will become free.
Detailed operation of the monitor is described on pp. 11-23.
If call transfer to your mobile phone has been programmed, you can cancel the transfer at any time from the monitor,
with it being necessary to communicate with the door panel from the main menu.
To make a call, the visitor must press the button of the apartment; an audible sound indicates that the call is being
made and LED will illuminate. At this moment, the apartment's monitor(s) receive(s) the call. If the visitor presses
the button for another apartment by mistake, the call can be cancelled by pressing the button for the correct
apartment.
The owner of the apartment can activate the lock release by holding the proximity key over the reader. If the proximity
key is held for three seconds, the auxiliary relay output will be activated.
In systems with several access doors, the other door panel(s) will be automatically disconnected. If another visitor
tries to call, a number of telephone tones will be heard to indicate that the system is busy and LED will illuminate.
Upon receiving the call, the image will appear on the screen of the master monitor (and slave 1, if it exists) without the
visitor knowing and icon displayed on the screen will blink green. To view the image from slave monitors 2 or 3,
press the screen for the image to appear. If the call is not answered within 45 seconds, LED will turn off and the
system will become free.
RECOMMENDATIONS
- before making modifications to the device.Always disconnect the power supply
- The wiring must run at least .40cm away from any other wiring
- Check all connections before starting the device.
- The installation and handling of these devices must be carried out by authorised personnel.
-Always follow the instructions contained in this manual.
- Preferably use a Golmar cable (2x1mm²).RAP-GTWIN/HF
