Goodwe BT Series User Manual

User Manual V1.3-2021-12-15 04 OTHER
34
4.4 Technical Parameters
Technical Data GW5K-BT GW6K-BT GW8K-BT GW10k-BT
Battery Input Data
Battery Type Li-Ion
Nominal battery voltage (V) 500
Battery Voltage Range (V) 180~600
Max. Charging Current (A) 25
Max. Discharging Current (A) 25
Max charge power (W) 5000 6000 8000 10000
Max discharge power (W) 5000 6000 8000 10000
Charging Strategy for Li-Ion
Battery
Self-adaption to BMS
AC Output Data (On-grid)
Nominal Apparent Power Output
to Utility Grid (VA)
5000 6000 8000 10000
Max. Apparent Power Output to
Utility Grid (VA)
*1 *6
5500 6600 8800 11000
Nominal Apparent Power from
Grid(VA)
10000 12000 15000 15000
Max. Apparent Power from Utility
Grid (VA)
10000 12000 15000 15000
Nominal Output Voltage (V) 400/380, 3L/N/PE
Output Voltage Range (V) 0~300
Nominal Output Frequency (Hz) 50/60
AC Grid Frequency Range (Hz) 45~55
Nominal Output Current (A) 7.2 8.7 11.6 14.5
Max. AC Current Output to Utility
Grid (A)
8.5 10.5 13.5 16.5
Max. AC Current From Utility Grid
(A)
15.2 18.2 22.7 22.7
Max. Output Fault Current(peak
and duration) (A)
45,2us
Inrush Current(peak and
duration) (A)
45,2us
Maximum output overcurrent
protection (A)
45,2us
