Google Pixel 6 Pro User Manual

Google 2021 | Confidential and Proprietary | Do not distribute 105
G730-06300-01
Battery
Battery replacement
Heat plate
Universal disassembly fixture
R4-Assy-Enclosure Holder &
Graphite Align
R4 Press cover
Universal press fixture
ESD tweezers
Feeler gauge
Universal adsorption-bulb
3M AP111 Primer
Tools Parts
The following
components
must be
removed first:
Prerequisites
Battery
There are two methods to removing a Battery from this device. Method 1 uses a holder clamped to the bench and the 2nd method involves 2 people.
Disconnect the Battery as soon as possible during service.
●
Display module
●
Graphite sheets
●
Mid-frame
●
mmWave
Caution!
To avoid a thermal event, ensure surfaces are free from debris and original shipping packaging is used to return parts.

Google Pixel 6 Pro Specifications

General

Processor	Google Tensor
RAM	12GB
Storage Options	128GB, 256GB, 512GB
Front Camera	11.1 MP
Battery Capacity	5003 mAh
Operating System	Android 12
5G Support	Yes
Water Resistance	IP68
Wireless Charging	Yes
Dimensions	163.9 x 75.9 x 8.9 mm
Weight	210 g
Display	1440 x 3120 pixels, 120Hz
Rear Camera	50 MP (wide), 48 MP (telephoto), 12 MP (ultrawide)
