Google Pixel 6 Pro User Manual

Google 2021 | Confidential and Proprietary | Do not distribute 118
01. Remove SIM tray
02. Remove screws
Logic board
●
Remove the SIM tray with a Universal Fish line.
Part: G852-02165-11 (SIM tray)
●
Place the R4 Screw cover on the R4 Enclosure holder.
●
Remove the 5 Logic board screws with a Torx Plus 3IP
screwdriver, remove the R4 Screw cover.
Part: G250-05752-00 (Screw)
Be careful to avoid scratching the Enclosure.
Do not reuse the part
Bottom spe
aker
MicLogic bo
ard
BatteryFront ca
mera
Top
Speaker
Rear ca
mera
Upper mid-f
rame
mmWaveMid-frameGraphic sh
eet
Display

Google Pixel 6 Pro Specifications

General

Processor	Google Tensor
RAM	12GB
Storage Options	128GB, 256GB, 512GB
Front Camera	11.1 MP
Battery Capacity	5003 mAh
Operating System	Android 12
5G Support	Yes
Water Resistance	IP68
Wireless Charging	Yes
Dimensions	163.9 x 75.9 x 8.9 mm
Weight	210 g
Display	1440 x 3120 pixels, 120Hz
Rear Camera	50 MP (wide), 48 MP (telephoto), 12 MP (ultrawide)
