Gorgy Timing LEDI Series - English

52
MDE-LEDI-1099V3.4
1. ASSEMBLY PRINCIPLE .............................................................................................. 54
1.1. Wall mount (MODèLE LEDI
®
, LEDICA
®
) ........................................................................... 54
1.2. Flush Mount (LEDI
®
, LEDICA
®
range) ............................................................................... 57
1.3. Mounting with bracket ......................................................................................................... 58
1.3.1. Adapter bracket for ceiling mount of LEDI® indoor clock single face (small size):
LEDI
®
5(s), LEDI
®
7(s), LEDI
®
5.60(s), LEDI
®
7.60(s). ..................................................... 58
1.3.2. Adapter bracket for ceiling mount of LEDI
®
Indoor clock single face (large size):
LEDI
®
10 (s), LEDICA
®
..................................................................................................... 58
1.3.3. Ceiling Mounting with bracket for LEDI
®
& LEDICA
®
Indoor clock double face ... 59
1.3.4. Side Mounting with bracket for LEDI
®
& LEDICA
®
Indoor clock double face ....... 60
1.3.5. Ceiling Mounting with bracket for LEDI
®
outdoor clock single face ...................... 61
1.3.6. Side Mounting with bracket for LEDI
®
outdoor clock single face .......................... 62
1.3.7. Ceiling Mounting with bracket for LEDI
®
outdoor clock double face ..................... 63
1.3.8. Side Mounting with bracket for LEDI
®
outdoor clock double face .......................... 64
1.3.9. Ceiling Mounting with bracket for LEDI
®
World ..................................................... 65
1.4. Dimensions of clocks and mountings (in mm) .................................................................... 66
2. GENERAL CHARACTERISTICS ................................................................................. 67
2.1. AVAILABLE VERSIONS (according to model):................................................................... 67
2.1.1. Standalone version: ............................................................................................... 67
2.1.2. Parallel minute impulse input: ................................................................................. 67
2.1.3. Series connection ½-minute impulse input: ............................................................ 67
2.1.4. AFNOR NFS 87500 input version ........................................................................... 68
2.1.5. Ethernet version synchronised by NTP (VAC or POE (Power over Ethernet)). ...... 68
2.1.6. DHW 869.525MHz Radio Version ......................................................................... 68
2.1.7. Radiosynchronised version using a DCF Antenna ................................................. 68
2.1.8. Radiosynchronised version using a TDF Antenna .................................................. 68
2.1.9. ASCII RS232 or RS485 Version ............................................................................. 69
2.1.10. SMPTE version ..................................................................................................... 69
2.2. OPTIONS AVAILABLE ........................................................................................................ 71
2.2.1. Pulse Output Option : ............................................................................................ 71
2.2.2. ASCII RS232 or RS485 output option .................................................................... 71
2.2.3. Date / time alternation option (only LEDI) ............................................................... 72
2.2.4. Temperature option ................................................................................................ 72
3. CONNECTIONS ........................................................................................................... 73
3.1. LEDI
®
model: Mains current/Time code/Display ................................................................. 73
3.1.1. Pulse receiver and AFNOR NFS 87500 time code receiver version ...................... 73
3.1.2. Radio-synchronized by TDF, DCF or GPS receiver version ................................... 74
3.1.3. DCF 24V wired version ........................................................................................... 74
3.1.4. Versions ASCII RS232 ou RS485 ........................................................................... 74
3.1.5. SMPTE Version ...................................................................................................... 74
3.1.6. NTP Version ............................................................................................................ 74
3.1.7. TOP option .............................................................................................................. 75
3.1.8. ASCII RS232 or RS485 output option ................................................................... 75
3.1.9. Temperature option ................................................................................................. 75
SUMMARY
