Gorgy Timing LEDI Series - Dimensions of Clocks and Mountings (in mm)

66
MDE-LEDI-1099V3.4
1.4. DIMENSIONS OF CLOCKS AND MOUNTINGS (IN MM)
Model
Height of gures
(hours and minutes)
A B
LEDI
®
5 50 235 145
LEDI
®
5.S 50 315 145
LEDI
®
5.S Hospital 50 375 164
LEDI
®
5.60 50 270 270
LEDI
®
7 70 350 165
LEDI
®
7. Outdoor 70 356 171
LEDI
®
7.S 70 430 165
LEDI
®
7.S Outdoor 70 436 171
LEDI
®
7.S Hospital 70 490 184
LEDI
®
7.60 & LEDI
®
7.60.S 70 390 390
LEDI
®
10 110 500 210
LEDI
®
10.S 110 640 210
LEDI
®
12 Outdoor 110 506 216
LEDI
®
12.S Outdoor 110 721 216
LEDI
®
15 Outdoor 160 760 315
LEDI
®
15.S Outdoor 160 950 315
LEDICA
®
7.M 70 625 165
LEDICA
®
7.M.S 70 715 165
LEDICA
®
ALPHA Square 7.M 70 390 390
LEDICA
®
ALPHA 7.M 70 650 220
LEDICA
®
ALPHA 7.M S 70 760 220
LEDICA
®
ALPHA 7.60.M 70 390 550
LEDICA
®
ALPHA 7.60.M.S 70 390 550
LEDICA
®
10.M 100 770 210
LEDICA
®
10.M.S 100 930 210
