3.1.2. Radio-synchronized by TDF, DCF or GPS receiver version
► Connect TDF, DCF or GPS antenna on the inputs CODE of plug-in terminal (no
polarity).
☛ To position your antenna, please refer to instructions on antennas
usermanual "MDE-ANTENNES-0085" available on:
CDG020/021 or web site www.gorgy-timing.fr section user manual.
3.1.3. DCF 24V wired version
► Connect DCF input to the terminal – and +
☛ Pay attention to the correct
polarity: wiring mistakes may cause
severe damages.
3.1.4. Versions ASCII RS232 ou RS485
► Connect ASCII RS232 or RS485 signal on the plug-in terminal according to table
below:
► After connecting the ASCII code, press the "reset" button on the back of the product.
3.1.5. SMPTE Version
► Connect SMPTE signal on the terminals "ASCII" and "GND".
3.1.6. NTP Version
► Connect Ethernet cable on Ethernet port located at rear panel of the product.
ASCII RS232C ASCII RS422/485
ASCII 1 Terminal TXD E / S -
BASCII 2 Terminal RXD E / S +
GND Terminal GND GND
T°C
DCF
DCF
+
Reserved Reserved
T°C
ASCII
232/485
E/S+ RXD
E/S- TXD
Attention to DCF code polarity
Attention polarité code DCF
Achtung: DCF Code Polarität
Atención con la polaridad del código DCF
