Gorgy Timing LEDI Series - Ceiling Mounting with Bracket for LEDI Outdoor Clock Double Face

63
MDE-LEDI-1099V3.4
1.3.7. Ceiling Mounting with bracket for LEDI
®
outdoor clock double face
165,2
A
B
150
3
=105==86=
=75=
=56=
142,5
122,5
40
33,2
165,2
=340=
=150=
=120=
4x 6,6
715
210
162
5
=150=
=200=
=120=
=170=
4x 6,6
pour vis de fixation
6
2 ETHERNET CABLE (POE + NTP)
LIAISON VERS HORLOGE "FILLE"
ENGLISH
