GPD Global CF-9 - Die Block Assembly

T
1
B
1
1
2
3
4
5
4
6
7
8
9
10
11
2
CF-9 User's Guide
8 GPD Global 09/30/92
Figure 4 Die Block Assembly, Station 1
Die Block Assembly
Item 1 Eccentric Crank Item 7 Die Mounting Area
Item 2 Crank Shaft Item 8 Cover Plate
Item 3 Micrometer Scale Indicator Item 9 Crank Adjuster
Item 4 Die Station Guide Shaft Item 10 Die Block
Item 5 Die Block Adjusting Bolt Item 11 Wear Plate
Item 6 Die Block Slide
Micrometer Scale Indicator
The micrometer scale indicator mounted on each die station makes the lead cut length
adjustment operation quick, easy, and highly accurate to .0005" (0.0127 mm).
