CF-9 Radial Component Lead Former
P/N 901-1-06 06/17/02 GPD Global
®
CF-9 Setup Sheet
Component
Part Number:
Part Description:
1. Set machine speed to zero (0). 7. Manually turn machine until first part exits machine.
2. Install dies as shown below. 8. Check component for proper form.
3. Adjust die stations to digital settings shown below. 9. Fine tune digital settings for proper form as required.
4. Manually turn machine to check alignment of dies. 10. Start machine.
5. Install ejector bracket if required. 11. Adjust machine speed to .
6. Load parts.
