GPD Global CF-9 - Specifications; Power Requirements

L
L
1
2
230 Volts
CF-9 User's Guide
09/30/92 GPD Global 29
Specifications
Power Requirements
120 Volt Model 230 Volt Model
120 Volts
Neutral
Safety (Earth) Ground
5 Amps
60 Hz Safety (Earth) Ground
2.5 Amps
50/60 Hz
Dimensions
Height........
Length .......
Width ........
Standard CF-9
12.00 inches
(304.80 mm)
13.25 inches
(336.55 mm)
13.50 inches
(342.90 mm)
CF-9 with
Reel Holder
Work Station
18.62 inches 29.50 inches
(472.95 mm) (749.30 mm)
13.25 inches 26.00 inches
(336.55 mm) (660.40 mm)
28.00 inches 39.00 inches
(711.20 mm) (990.60 mm)
CF-9
Weight
Standard CF-9 .............................................58 lbs. (26.31 kg)
Capacities
Production Rate
The CF-9 is capable of forming and cutting up to 25,000 components per hour.
Micrometer Scale
Display increments to .0005" (0.0127 mm)
±.002" Repeatability
