CF-9 User's Guide
09/30/92 GPD Global 27
d. Position die block assembly approximately 1" (25.40 mm) from machine upright plate
using die block adjusting bolt.
e. Lay machine on its back cover with die blocks up and cabinet's back air vent clear.
Run machine in this position for approximately one (1) hour to allow oil to distribute
evenly. During this time period, slowly increase machine speed and check cover
plate and die block for heat.
C A U T I O N
I
F EXCESSIVE HEAT IS DETECTED OR A SQUEAK IS HEARD
,
STOP THE MACHINE
.
R
EPEAT
COMPLETE
S
LIDE
C
LEARANCE PROCEDURE
.
f. Reassemble the following:
• Digital scale lower mounting block screws
• Belt guide and pressure plate
• Component transfer belt (Adjust so belt is taut.)
• Tape exit chute
• Die screws
g. Reset slide travel adjustment - refer to Slide Travel on page 24.
