BLINE
Description
Define black mark distance and extra label feeding length after printing
Syntax
(1) English system (inch)
BLINE m, n
(2) Metric system (mm)
BLINE m mm, n mm
Parameter Description
m The distance between two black marks
0.1 ≤ m ≤ 1 (inch), 2.54 ≤ m ≤ 25.4 (mm)
n Extra label feeding length (inch or mm)
0 ≤n ≤label length (inch or mm)
0,0 Continuous label.
Note: For metric system, there must be a space between parameter m and mm.
When the sensor type is changed from “GAP” to “Black Mark”, please send the
“BLINE” command to the printer first.
Eg: In DOS mode,
C:\>COPY CON LPT1 <Enter>
BLINE 2 mm,0<Enter>
<Ctrl>+<Z><Enter>
Example
(1) English system (inch)
BLINE 0.20,0.50
(2) Metric system (mm)
BLINE 5.08 mm,12.7 mm
See Also
SIZE, GAP
